PICASSO artificial grass

PICASSO artificial grass

Specifications for searchings
Level of use: intense, it is going to be stepped on continuously Degree of comfort: very high Level of resilience: very high Degree of real-life appearance: very high Degree of softness: high Pile height ( mm )40 Pile weight ( gr/m2 )2260 Density ( stitches/m2 )28350 Fire resistance clasification CE marking Micromonofilaments Warranty period: 7 years
SUITABLE LEVEL OF USE TYPICAL USES
 Intense, it is going to be stepped on continuously  Gardens of apartment block communities, condominium communities, community pools, etc...
 High, it will be stepped on frequently  Private gardens, swimming pools or any other frequently walked-on area
 Medium, you will step on it just occasionally  Private gardens, terraces, penthouse apartments, swimming pools or other less frequented areas
 Low, merely decorative  Ornamental, decorative gardens, roundabouts, separators, shop windows, fairs, events, etc...


PICASSO: "I do not believe in the muses, but if they do arrive, they´ll find me working"


Inspiration, dedication, hard work, creativity, and rigour are the driving forces behind PICASSO artificial grass

The PICASSO model has always been a key reference in the market, and it is considered one of the best and most advanced models available anywhere

It is made with the latest yarn, which is composed of "concave U-shaped micro monofilaments" ( which help to reduce heat absorption ). It is extruded by using high quality polymers which have undergone matte treatment, and also by using UV resistant additives and the most advanced chromatics currently available

It is manufactured with a pile height of 40 mm and has a density of 27,300 stitches / m2. Along with the extraordinary yarn used in its production, these characteristics result in a very soft grass and it gives the feeling of being padded when it is stepped on ( it has more than 2,300 gr / m2 ). In addition to this, its recovery capacity after being walked on is simply outstanding and it is amazingly resistant, while still being spongy and very pleasant to walk on

Not only does it have top quality yarn, but the product also has a top quality backing, which was specially created using materials which give the best dimensional stability available

PICASSO artificial grass has an 8-year guarantee for UV resistance ( applicable in areas of 200 w / m2. See warranty section for further details ), and has the "Efl" fire certification in accordance with the EN 13501-1 standard

How many models are there on the market that can offer both the quality and quantity of yarn with the same level of excellence as our PICASSO model ? Not very many we guess

"We do the impossible, because anyone can do what is possible" ( Pablo R. Picasso )

Formats and dimensions


Technical characteristics of the yarn


 DTEX  9500
 Filament configuration  8 straight + 8 curly
 Straight yarn
 Structure  Micromonofilament ( MMF )
 Shape  Concave in U
 Thickness  130-150 µm
 Width  0,76-0,82 mm
 Composition  Polyethylene
 Colour shade  Two-tone green ( two colours )
 Matte treatment  Yes
 UV stabilised  Yes
 Respectful with the environment  Yes, lead and cadmium free
 Curly yarn
 Structure  Texturised
 Composition  Polypropylene
 Colour  Beige and green

Technical characteristics of the backing


 Primary support composition  Polypropylene + net
 Primary support layers  2
 Reinforced with net  No
 Primary support weight  150 grammes / m2
 Support coating  Latex
 Support coating weight  900 grammes / m2

General technical characteristics


 Type of manufacturing system  Tufted cut pile + curly yarn
 Gauge  3/8”
 Stitches per m2  27300 ( +/- 10% )
 Stitches rate per 10cm  26 ( +/- 1 )
 Pile height  40mm ( +/- 5% )
 Total height  42mm ( +/- 5% )
 Pile weight  2334 gr /m2  ( +/- 10% )
 Total weight  3384 gr /m2  ( +/- 10% )
 Dimensional stability  +/- 0,60 %
 Water permeability  50 litres / minute / m2
 Installation  Floating without silica sand infill ( optional )
 Fire resistance clasification  Efl-s2

Information for invitation to tender
